UAV2000 Meteorological Observation UAV

· Maximum flight height 500m (electronic height limit)
· Support measurement of temperature, humidity, pressure, wind speed, wind direction and other parameters
· Quick-disassembly integrated design, easy installation and maintenance
· Sustainable maximum flight of 40 minutes
· Support LoRa / USB-C communication







Meteorological Observation UAV





      UAV2000 is a compact meteorological obersvation UAV(Unmanned Aerial Vehicle), with measurement of temperature, humidity, air pressure, wind speed, wind direction and other parameters. The overall design integrates the requirements of ergonomics and aviation meteorology, and adopts the concept of modular, solid and digital sensors, which can quickly measure meteorological parameters and improve the access to information on the speed and accuracy. With the mature UAV platform, the sensor type and camera platform can be changed according to the actual detection needs.  Multiple UAV joint operation can coordinate the system with accurate sychronization. In the data analysis platform, horizontal and vertical data distribution diagram can be presented according to the GPS and terrain.The atmospheric 3D state can be calculated and displayed.
Combining the meteorological obersvation equipment and UAV, it can better serve the modern meteorological needs, provide more convenience for the meteorological observation outdoor operations free from geographical restrictions and provide cost advantages.









Technical parameters




Aircraft general parameters



  Maximum flight height   500m(electronic height limit)

   Maximum take-off altitude

     6000m

Maximum ascent speed

  8m/s

Maximum descent speed

  6m/s

Hover time



No load, >30min; maximum takeoff weight, >15min

Control distance

  8km

Control height

  6km

Frequency

  2.4GHz

Maximum take-off weight



1176g (aircraft + micro weather station)

Bare weight

  958g

Camera

  5.1K/50fps, 4K/120fps

Storage capacity



32G TF standard

Communication interface

  USB-C
Operating temperature   -10℃~40℃

Operation humidity

  10%RH~80%RH

Dimension

  473mm×413mm×249 mm

Certificates

  CE,FCC


Micro weather station technical parameters



Temperature measuring range   -40℃~50℃
Temperature  accuracy   ±0.3℃,±0.2℃(5℃~35℃)
Temperature  resolution   0.1℃
Humidity measuring range   0%~100%RH
Humidity  accuracy

±3%RH(15%RH~85%RH),±5%RH

 (other range)

Humidity  resolution   0.1%RH
Pressure measuring range   500hPa~1100hPa
Pressure measuring accuracy   ±1Pa
Pressure measuring resolution   1hPa
Wind speed measuring range   2m/s~30m/s
Wind speed measuring accuracy   ±1m/s(≤15m/s),      ±5%(>15m/s)
Wind direction measuring range     With 16 direction recognition
  Communication and Storage     LoRa (USB receiver included); USB-C, supports SD card data recording and export

Power supply



5V DC, 2A max (built-in battery)

Battery



Lithium polymer battery, 3.7V 1200mAh

Dimension

   229mm×90mm×173mm
